Features:
Ultra-light---lighter 40% than aluminum die-csting cabinet.
High precision---seamless splicing though CNC machining.
Super slim---high-strength,more slim than aluminum in the design,thiner around 30%.
Easy installation---installed by quick lock for 20s only.
High protection grade of IP65 guarantees,Durability, Reliability, Anti-ultraviolet and Steady.
Dual channel heat dissipation
Low power consumption and fast heat dissipation/ energy saving and environment protection.
Super wide angle
Wide Viewing Angle can achieve to Vertical viewing 150 Horizontal viewing 120.
Ultra thin and ultra light
|
Pixel Pitch(mm) |
10 |
|
Pixel Density(dot/m2) |
10000 |
|
Module Pixel Matrix (W×H) |
32×16 |
|
Module Size(mm) |
320(W)×160(H) |
|
Module Weight(kg) |
0.8 |
|
Module Power Consumption Max.(W) |
40 |
|
Module/Panel(W×H) |
3x6 |
|
Panel Resolution(W×H) |
96×96 |
|
Panel Size(mm) |
960(W)×960(H)×160(D) |
|
Panel Weight(kg) |
35 |
|
Maintenance Mode |
Rear Maintenance |
|
Panel type |
Steel cabinet |
|
Brightness(nits) |
≥6500 |
|
Color Temperature(K) |
3200—9300 |
|
Viewing Angle(Hor/Vert°) |
140/120 |
|
Power Consumption Max(W/m2) |
1000 |
|
Power Consumption Avg(W/m2) |
200-300 |
|
Operating Power Source |
AC90~264V,Frequency 47-63(Hz) |
|
Frame Frequency(Hz) |
50&60 |
|
Drive Mode |
Constant Driving,1/2S |
|
Gray Scale |
65536 |
|
Refresh Rate(Hz) |
≥1920 |
|
Gray Scale per Color Level |
16bit |
|
Working Temperature/Humidity(?/RH) |
-20 – 60 / 10%-85%RH |
|
Storage Temperature/Humidity(?/RH) |
-20 – 60 / 10%-85%RH |
